Spindle gear:
White: 80.8A 81A 81.5A 82A 102A 122A 132A 142A 182A (a total of 9 each)
Blue: 153AD, 152.3A, 15.317A, 154AD (4 in total)
Worm model: 6 * 62A 6 * 82A (one each, total 2)
Umbrella tooth: S162A (1 pc)
In addition, 10 2MM shaft sleeves are presented, total quantity: 26
About model identification:
This product is 0.5 module, gear diameter = (number of teeth + 2) * module
Such as 81.5A gear:
8 represents: eight teeth, gear diameter = (8 + 2) x0.5 = 5MM
1.5A stands for: tightly matching the 1.5MM motor shaft, that is, the aperture of the gear is actually 1.45MM, before it can be tightly matched with the 1.5MM motor shaft!
Such as: 153AD gear
15 represents: 15 teeth, gear diameter = (15 + 2) X0.5 = 8.5MM
3AD stands for: 3 stands for 3MM motor shaft, A stands for tight fit, and D stands for D axis motor. It is summarized as: close to the D axis gear of 3MM motor.
